Flapping Type Test Sieve
XC flap screen( flapper standard vibration sieve machine) also known as slap-type vibrating screen, is one of the commonly used laboratory testing equipment, consisting of engine base,sifter, transmission parts etc. Be applied to test the composition of common abrasive particle size and super-hard material particle size, and grading the super-hard material.
- Product Introduction
XC flap screen( flapper standard vibration sieve machine) also known as slap-type vibrating screen, is one of the commonly used laboratory testing equipment, consisting of engine base,sifter, transmission parts etc. Be applied to test the composition of common abrasive particle size and super-hard material particle size, and grading the super-hard material.
Flap standard vibration sieve machine consists of engine base, sifter, gear etc.
This machine can be equipped with special fixture, can clamp 200 standard screen, and can be clamped Phi 75, Phi 100 sieve, clamping is convenient and flexible, firm clamping, and can automatically stop.
Product advantages
1. Structure is more compact, body weight is lighter
2. More durable, lighter, faster and more convenient
3. More simple to maintenance, easy to buy and repair the parts
4. High efficiency, with two function of reciprocating and rattling at the same time
5. Screen surface without block, feeding material quickly, screening completely
Xianchen flap sieve is applied to test the composition of common abrasive particle size and super-hard material size, and grading the super-hard material, and is also widely applied to some scientific research and production laboratory to screen and test these materials such as geology, metallurgy, powder, chemical industry, construction cement, medicine, national defense etc.
It' s especially better for diamond micro-powders and super-hard material's producing and grading, using repeatedly with high strength and large frequency.
|
No. |
Name |
Value |
Unit |
|
1 |
Times of rotations |
290(+-)6 |
Times/min |
|
2 |
Times of shots |
156(+-)3 |
Times/min |
|
3 |
Rotation stroke |
25 |
mm |
|
4 |
Slap height |
38(+-)6 |
mm |
|
5 |
The diameter of sieve |
200,150,100,75 |
mm |
|
6 |
The number of sieve |
1-7 |
layer |
|
7 |
Voltage |
380 |
v |
|
8 |
Power |
0.37 |
kw |
|
9 |
Rotating speed |
1500 |
r/min |
|
10 |
Dimension |
520*395*685 |
mm |
|
11 |
Net weight |
75 |
kg |
